Vol. 1
MOTOROLA Sec. 3
E-944

450-470 MHz HT 220 Series

"Handie-Talkie” FM Radios

450-470 MHz 1.0 Watt RF Output

«n I
ft

5942

4

Extended Duty Remote Speaker Selective Call
Basic Model Cycle Model Universal Model Microphone Model Model

The NEWEST “PEOPLE FINDER”... personal FM radio for operation on uncrowded
UHF channels!
COMPACT—The latest state of the art in personal 2-way radio— RUGGED CONSTRUCTION—The latest in integrated circuits and high
it’s about half the size and weight of the 200 series. At a mere density design of components has been utilized to achieve op­
21 ounces you can easily slip this radio into a jacket, clip it to timum space reduction with increased reliability. The separate
your belt, or wear it with a carrying case. The high impact plas­ transmitter and receiver sections are built on an entirely new
tic housing with pebble grain slip-proof finish is sealed to pro­ glass epoxy circuit board. The I-beam frame surrounds all com­
tect the unit from dirt and moisture and withstands damaging ponents protecting them from damage. Reliability is achieved
blows. All controls are mounted for easy and convenient opera­ with the double-sided etched circuitry and built-in eyelets, a
tion. You are assured of operating dependability and top per­ result of plated through holes which securely hold all elements
formance whenever you need it.
in place.
POWERFUL-SENSITIVE—1.0 watt of RF transmitter output power
provide customer with outstanding transmitter range. A new RAPID CHARGE CAPABILITY—With fast charger, unit can be charged
standard for portables in increased receiver sensitivity means for eight hours service in just sixty minutes! User can charge
extra range in weak signal areas. Five hundred milliwatts of his radio for a full shift during his lunch hour.
audio power produce loud, sharp, undistorted voice quality; OPTIONAL MATCHED ACCESSORIES — Available accessories include:
you’ll get the message even in high-noise areas. black carrying cases and belt—a chest pack designed to hold
SIMPLIFIED SERVICE—Removal of the back cover provides access the complete radio in a comfortable working position—five
to tuning adjustments and metering points. With no connec­ nickel-cadmium battery chargers, single unit, 12 unit, single
tions to unsolder, a minimum of cabling and wires means unit rapid charger, multiple unit rapid charger, and a vehicular
greater reliability and faster servicing. The color coded meter­ charger-storage rack combination. Motorola also offers special
ing points are readily accessible and identified by a label inside accessories for surveillance operation, belt clips, straight or coil
the back cover. cord microphones, voice operated relay, safety helmet headset
MULTI-CHANNEL CAPABILITY—Up to six frequencies on transmit and combination etc. Your Motorola representative is specially
receive in most models; this gives the user the very widest trained to recommend the proper optional accessories to fit
choice in system design. system requirements.
