Vol. 1
Sec. 3
E-945

450-470 MHz HT 220 Series

"Handie-Talkie” FM Radios

450-470 MHz 4 Watt RF Output

Remote Speaker Selective Call
Basic Model Universal Model Microphone Model Model

The NEWEST “PEOPLE FINDER . . . personal FM radio for high-power operation
on uncrowded UHF channels.
COMPACT—The latest state of the art in personal 2-way radio— RUGGED CONSTRUCTION—The latest in integrated circuits and high
it’s about half the size and weight of the 200 series. At a mere density design of components has been utilized to achieve op­
28.5 ounces you can easily slip this radio into a jacket, clip it to timum space reduction with increased reliability. The separate
your belt, or wear it with a carrying case. The high impact plas­ transmitter and receiver sections are built on an entirely new
tic housing with pebble grain slip-proof finish is sealed to pro­ glass epoxy circuit board. The I-beam frame surrounds all com­
tect the unit from dirt and moisture and withstands damaging ponents protecting them from damage. Reliability is achieved
blows. All controls are mounted for easy and convenient opera­ with the double-sided etched circuitry and built-in eyelets, a
tion. You are assured of operating dependability and top per­ result of plated through holes which securely hold all elements
formance whenever you need it.
in place.
POWERFUL-SENSITIVE—4 watts of RF transmitter output power
provide customer with choice of transmitter range to fit his RAPID CHARGE CAPABILITY—With fast charger, unit can be charged
requirements. A new standard for portables in increased re­ for eight hours service in just sixty minutes! User can charge
ceiver sensitivity means extra range in weak signal areas. Five his radio for a full shift during a lunch hour.
hundred milliwatts of audio power produce loud, sharp, undis­
torted voice quality; you’ll get the message even in high-noise OPTIONAL MATCHED ACCESSORIES — Available accessories include:
areas. black carrying cases and belt—a chest pack designed to hold
SIMPLIFIED SERVICE—Removal of the back cover provides access the complete radio in a comfortable working position—five
to timing adjustments and metering points. With no connec­ nickel-cadmium battery chargers, single unit, 12 unit, single unit
tions to unsolder, a minimum of cabling and wires means rapid charger, multiple unit rapid charger, and a vehicular
greater reliability and faster servicing. The color coded meter­ charger-storage rack combination. Motorola also offers special
ing points are readily accessible and identified by a label inside accessories for surveillance operation, belt clips, straight or coil
the back cover. cord microphones, voice operated relay, safety helmet headset
MULTI-CHANNEL CAPABILITY—Up to six frequencies on transmit and combination etc. Your Motorola representative is specially
receive in most models; this gives the user the very widest trained to recommend the proper optional accessories to fit
choice in system design. system requirements.
