ENGINE COOLING WIND TUNNEL 6.

I

PROPOSED WIND TUNNEL (Continued)
e
Uti1i ties (Continued)

Water, air, and oil fuel supplies shall be connected into the

Impact Building systems.

Indolene (standard Tab. gasoline) supply to test cars shall be

from a new tank to be situated outside the security fence east

of the Impact Building.

Site ; ’

The size of the- site is expected to be approximately 200' X 250

Access to the site shall be by roadway south of Impact Building

Parking shal1 be provided for eight cars on the north side of

the 1 oadway. The Wind Tunnel shall be south of the roadway

and set back approximately 85'.

The area between the Wind Tunnel and the roadway and for a

distance of approximately 20* around the Wind Tunnel shall be

graded and landscaped.

Wind Tunnel Layout
. f
The entrance of the Wind Tunnel shall be by pedestrian door

off the driveway, leading directly into the support area.

Access to the office, washroom and storage space shall be

from the support area.

The office shall hold three desks and associated office equip­

ment and shall be air conditioned. The washroom facilities

shall be available for men only.
