P. 15

Standard Shock
                        Absorber

                 REMOVAL


                 Wedge upper seat in top position following
                 removal procedure A-l.
                 Remove preload on torsion bars following
             C
                 procedure similar to removal procedure A-2.
             M
                 Do not disengage adjuster assembly
                 from seat.
              U)  Remove seat cushion only following
                 removal procedure A-4.
                 Wire side panel assemblies (index Nos.
                 28 and 29) across front of seat to retain
                 their position.
                                                                  Replace (2) roll pins (index No. 20)
                 Remove (2) snap rings (index No. 10)         (N
                 from ends of hinge shaft (index No. 18)          in hinge shaft, locking roll pin on right hand
             ID
                 at front of shock absorber.                      side in nibs in bent-up ear.
                 Remove hinge shaft (index No. 18)            C D  Replace hinge shaft (index No. 18)
             (D
                 by tapping out from left hand to right hand      at front of shock absorber, driving shaft from
                 side. This operation frees (2) washers           right hand to left hand side. Serrated end
                 (index No. 15).                                  of shaft to enter shock lever (index No. 17)
                 Remove (2) roll pins (index No. 20)              last. Drive shaft through (2) washers (index
             X
                 from hinge shaft at rear of shock absorber.      No. 15) and through shock absorber loop.
                 Use small Dia. punch.                         -U  Replace (2) snap rings (index No. 10)
                 Remove hinge shaft (index No. 19) at rear        at ends of front hinge shaft (index No. 18).
             C D
                 of shock absorber. This frees shock absorber.  Ul   Line up side panels right hand and
                                                                  left hand retaining the 20.00 dimension over
                                                                  side panels.
                 ASSEMBLY                                       0)  Reassemble seat cushion following
                                                                  assembly procedure A-4.
                                                                X
             1 With shock absorber (index No. 22)                 Preload torsion bars by rotating adjuster
                in proper position, replace hinge shaft         D  lever assembly (index No. 30) clockwise.
                (index No. 19) at rear of shock.                C   Remove shims.



                 OPTIONAL EQUIPMENT



                 INTERCHANGEABLE CUSHION COVERS. New Feature
                                          on Viking Seats
                                         If either cover is damaged and
                                         requires replacement, the opera­
                                         tion is simple. Remove cushion
                                         from seat frame. The vinyl cover
                                         is held in place by fastener clips.
                                         By opening the clips the cover
                                         is removed quickly and easily.
                                         A new foam cushion and fastener
                                         clips are included with each
                                         cover assembly.

 x
                Optional Equipment (available at extra cost)
                EXTRA DUTY SHOCK ABSORBER — For exceptionally
                severe operating conditions — off highway or over
                rough terrain — gravel or dump truck, concrete mixers,
                earth moving or similar equipment. This option can
                be used if seat to floor clearance is 21/^" or more.
                See your dealer for further information.
                ARM REST—Easily attached to side panel assembly.
                Folds up out of the way when not in use.
                SAFETY BELT KITS — Can be easily installed as shown
                in illustration.
