EXPLODED VIEW
DELUXE THINLINE

/
z____

NOTE: POINTS (a) connect in final assembly

OPERATING
INSTRUCTIONS

Your Deluxe Thinline seat has been fac­
tory assembled to suit a driver of average
weight. For individual comfort adjustment
follow this procedure:
Referring to exploded view, unzip the
back cushion cover at lower rear, ex­
posing the weight adjustment bolt
mechanism.
To adjust for additional weight con-
trol, turn bolt (item 15 on diagram)
clockwise.
To adjust for lower weight, turn bolt
counterclockwise.

The descriptions and specifications contained in this manual were in effect at the time the book was approved for
printing. UOP Bostrom Division, whose policy is one of continuous improvement, reserves the right to discontinue
models at any time, or to change specifications or design, without notice and without incurring obligation.
