INSTALLATION INSTRUCTIONS

DELUXE THINLINE
Mount seat with minimum wheel to
back clearance of 10" with back
and rails in rearward position. POSITION POSITION
Minimum wheel to seat clearance
of 6" with seat cushion in lowest \ ip
REAR FRONT
position.
IN IN
SEAT ____________16.50 MIN
CUSHION 17.25 MAX. i T W
CAM CUSHION CUSHION
r-1.75
ADJUSTMENT
BACK BACK

WITH WITH
24.00 25.00

“ti-------
1 H-00-
FORWARD
.75 CLEARANCE BELOW SLIDE RAILS
NECESSARY TO ALLOW FOR SEAT DEFLECTION

STANDARD

Designed as a Companion Seat to the Deluxe
Thinline — The Standard Thinline offers the same
rugged construction and styling. May be ordered
with or without slide rails (4" Fore and Aft Ad­
justment) — Either hinged or fixed back.
