BDSTHDM™THINLINE BUCKET SEATS

MOUNTING DIMENSIONS • PAST NUMBERS & PRICE LIST

DELUXE THINLINE
Mount seat with minimum wheel to
back clearance of 10" with back
and rails in rearward position. POSITION
Minimum wheel to seat clearance fr
of 6" with seat cushion in lowest
position. FRONT
IN
SEAT 16.50 MIN II
CUSHION 17.25 MAX.
CAM CUSHION
ADJUSTMENT
BACK v
WITH

25.00

FORWARD ADJ,
.50-
.75 inch clearance below slide rails necessary
for mounting to allow for seat deflection

List
Part No. 29910-3 Deluxe Thinline, complete $101.09
Part No. 22858-1 Universal Riser Kit........................................... 5.12

STANDARD THINLINE Mount seat with minimum wheel to
back clearance of 10" with back
and rails in rearward position.
Minimum wheel to seat clearance
of 6" with seat cushion in lowest
position.
OVERALL

-2 2 .0 0
1 inch clearance necessary for mounting
seat deflection

—
R-H
____J 1.50^____
t ^WTG. HOlE^
23.00 OVERALL

List
Part No. 29900-1 Fixed Back — No Slide Rails.......................... $53.13
Part No. 29905-1 Fixed Back — With Slide Rails....................... 62.53
Part No. 29919-1 Hinged Back — No Slide Rails....................... 56.79
Part No. 29920-1 Hinged Back — With Slide Rails................... 66.19
Part No. 22858-1 Universal Riser Kit......................................... 5.12
F.O.B. Milwaukee, Wisconsin — List prices do include F.E.T.
