H. P. Bruns - 4 - April 8, 1970

d. The Dodge test car will be returned from Chelsea and rebuilt for
engine testing at Daytona early in May.

2. Instrumentation and Electronics Support

a. Grand National Cars

The Dodge test car will be partially instrumented for high speed runs
at Chelsea with the following measurements:

Propellor Shaft Torque
RPM
Carburetor Air Pressure
Wheel Speed
Yaw
Aerodynamic Pressures

The Plymouth test car will be instrumented for Darlington tests with
the following measurements:

Suspension Displacement (4 wheels)
Engine RPM
Steering Wheel Position
Yaw
Carburetor Air Pressure
Acceleration (2 axis)

b. Tran Am Car IQ

Instrumentation installed in the untested Trans Am Barracuda will
remain with the car for tests planned the first week in April.

c. Drag Cars

Three drag test cars will be instrumented for tests at Cecil County
Dragway, Maryland, 13-15 April 1970.

The following measurements will be made:

Engine RPM
Propellor Shaft RPM
Front Wheel Speed
Longitudinal Acceleration
