AIR VIKING PARTS LI How To Use:

A
ORDERING INSTRUCTIONS: (Order by Part Number, NOT Index Number). Find the corresponding part that you wish to
A replace on the exploded view illustration and
ORDER FROM: Your truck dealer or the Bostrom distributor for your area. note its index number, refer to index list
J below and record part number, quantity required
BE SURE TO SPECIFY: Serial number and description. Replaceable components of an
(see exploded view for location of serial number), part number s assembly are indented under that assembly,
and description as listed below and quantity required. indicating that they can be ordered separately or will
be included if the assembly is ordered.
A

Index Part
No. No.
1 38197-1 BASE ASSEMBLY, w/Bearings
14 23838-801 BEARINGS, Flanged
2 25770-801 OUTER LEVER ASS’Y., w/Pins and Bearings
3 26020-801 BEARINGS, Flanged
4 25779-801 PIN DRIVE
5 38198-1 CENTER LEVER ASS’Y. KIT
6 27191-801 BEARING, Housing, L.H.
7 25775-801 BEARING, Housing, R.H.
60 31015-801 RIDE LEVEL INDICATOR
8 25690-801 ROLLER AND BEARING ASS’Y.
9 25777-801 STUD
12 25989-801 SNAP RING
11 26988-802 WASHER, Plain
12 *353019-801 LOCKWASHER, % SAE Med.
13 *350003-801 NUT, Hex. %-16 (UNC-2B)
15 353042-801 WASHER, Plain, % x %x 7 Ga.
16 60470-1 SHOCK LEVER ASS’Y. KIT
17 SHOCK LEVER ASS’Y.
18 25790-802 HINGE SHAFT, Shock
19 25789-801 HINGE SHAFT SHOCK REAR
20 22525-801 ROLL PIN
21 60475-1 SHOCK ABSORBER ASS’Y. KIT
18 25790-802 1 HINGE SHAFT, Shock
22 1 SHOCK ABSORBER ASS’Y., w/Bearings
23 60477-1 1 BEARING KIT (Shock Absorber)
18 25790-802 1 HINGE SHAFT, Shock
24 22506-801 4 BEARING, Flanged
27 *351168-801 4 CAP SCREW, %-16 (UJC-2A) x %
28 36699-809 1 SIDE PANEL ASS’Y., L.H.
29 36387-808 1 SIDE PANEL ASS’Y., R.H.
30 36670-811 1 AIR RESERVOIR ASS’Y.
33 36901-801 1 HOSE ASS’Y. KIT
26 36971-801 2 RETAINER CLIP
32 36970-801 1 RETAINER CLIP
25 *954006-801 1 SEAL “O” RING /e"
43 *954007-801 2 SEAL “O” RING ft"
34 38199-2 1 VALVE ASS’Y. KIT
35 1 WASHER, Bowed
36 1 WASHER, Flat
37 1 NUT
38 1 BUTTON
25 *954006-801 3 SEAL “O” RING (2 in valve ass'y.)
32 36970-801 3 RETAINER CLIP /8" (2 in valve ass'y.)
39 34877-7 1 AIR SPRING ASS’Y. KIT
31 1 MALE PIPE FITTING ASS’Y.
43 *954007-801 1 SEAL “O” RING
40 *353047-801 1 LOCKWASHER, %6 Ext. Tooth, Zinc Plate
41 *349014-801 1 MACHINE SCREW, Xe-18 (UNC-2A) x %, Phillips, Zinc Plated
42 27193-801 8 LUB FITTING % Shank)
44 25778-801 1 LUB FITTING (’& Shank)
45 30064-801 2 ROLLER (Nylon)
46 *353043-801 4 WASHER, Plain %x%xX6
47 *353024-801 12 LOCK WASHER SAE Med. Zinc Plated
48 *351119-801 8 NUT, Hex, >(6-18 (UNC-2B) Zinc Plated
49 351137-801 4 CAP SCREW, ^6-18 (UNC-2A) x % Fi II ister- Ph i 11 i ps
50 31604-801 1 LATCH WIRE
51 32118-1 1 ADJUSTER KIT — Includes right and left hand rails and latch wire.
52 *351152-801 4 CAP SCREW, ^6-18 (UNC-2A) x % Fi 11 i ster-Ph i 11 ips Zinc Plated
53 27194-801 4 BUMPER, Bottom (53A) and Topping (53B)
54 25998-503 (Black) 1 SEAT CUSHION ASS’Y. Includes pan, cover, pad and fastener clips
55 25998-502 (Black) 1 COVER ASS’Y. KIT, Seat Cushion. Includes cover, pad and fastener clips
55A 25996-806 1 PAN ONLY, Seat Cushion
56 28630-503 1 BACK CUSHION ASS’Y., Space Saver. Includes pan, cover, pad and fastener clips
57 28630-502 1 COVER ASS’Y. J<IT, Space Saver Back Cushion. Includes cover, pad and
fastener clips
57A 28346-802 1 PAN ONLY, Space Saver Back Cushion
59 27040-801 12 FASTENER CLIP, Cushion
STANDARD SEAT ASSEMBLIES
35805-1 AIR VIKING with Space Saver Back Cushion w/o Risers (Black Trim)
38003-1 AIR VIKING with Space Saver Back Cushion and Universal Risers (Black Trim)
° n
‘"Commercially available at hardware outlets. The descriptions and specifications contained in this manual were in
effect at the time the book was approved for printing. UOP Bostrom
Division, whose policy is one of continuous improvement, reserves
the right to discontinue models at any time, or to change specifica­
tions or design, without notice and without incurring obligation.
