AIT1 VIKING

SUSPENSION SEAT

ADDS OPERATOR VALUES
TO VOUR TRUCKS

This new Bostrom Air Viking gives you all the
proven dependability, quality, and features of
the famous Viking T-Bar in addition to air
suspension.
Like all Bostrom suspension seats, the Air
Viking can be adjusted to each driver’s weight
and size. An easy to operate push-pull air
valve quickly puts the driver in the center of
a four inch ride zone. Fore-and-aft as well as
back cushion angle adjustments add to driver
comfort and efficiency.

■ 9
RECOMMENDED INSTALLATION INSTRUCTIONS

Measure distance from old cushion
contours to steering wheel and place Air­
Viking in same position or use recom­
mended dimensions shown in drawings.
Note: Check truck cab floor for adequate
•sc- rigidity after seat is installed and
strengthen floor if necessary.

Universal Risers Pan no. 2285s-i
When mounting, be sure risers are parallel and square
and installed as shown in illustration. By using
combinations of the upper holes only, the angle and height
of the seat can be adjusted to suit the individual.

AIR SUPPLY LINE
CONNECTOR 15"
When purchasing hose to WHEEL TO BACK CUSH.
connect seat with truck air (Rear Position)
line, length of hose is de­
termined by moving seat to k
maximum forward position
and raising to top elevation
(air spring fully inflated).
Hose should be of a flex­
ible material, not rigid. Re­ 1" CLEARANCE
inforced rubber is recom­ NECESSARY BE­
TWEEN BACK OF
mended; do not use metallic SEAT AND CAB
tubing.
Hose should be connect­
ed to dry tank of truck.
9.57 MAX.
INCREMENTS

2
