LIST OF FIGURES

Figure No. Titl re

1 Aerodynami a Axis System

Correlation of Wind Tunnel Data from the Lockheed-
Georgia and Wichita State University Tests

Aerodynami Lift and Side Force Characteristics of
the 1969 Race Charge

The 1969 Race Charger and the Charger Daytona

Aerodynamics of the 1969 Race Charger and Charger
Daytona

Aerodynami n Lift and Side Force Characteristics of
the Charge Daytona

Axial Force Characteristics of the 9” and 18” Charge
Daytona Front End Extensions

Front Undernose Spoiler Effectiveness on the 1969
Race Car and the Charger Daytona

Effects of Front Undernose Spoiler Position on the
Aerodynamics of the Charger Daytona Front End

10 Effect of Vehicle Attitude on The Lift and Axial
Force of The 1969 Race Car and the Charger Daytona

11 Effect of Rear Deck Stabilizers on the Lift and Axial
Force of The Charger Daytona
12 Effect of Backlight Angle on Axial Force and Rear Axl
Lift Coefficient (Normalized to a full fastback back­
light)

*28-
