ITEM NO. DESCRIPTION PART NO. ITEM NO. DESCRIPTION PART NO.

RESISTORS (Cont.) TRANSFORMERS

R64 J6.8K ± 10% 1/2W. Carbon T1 Power Transformer 301-162
R65 NOT USED T2 Audio Driver 301-170-1
R66 8202 ± 10% 1/2 W. Carbon T3 Audio Output 301-170-2
R67 1502 ± 10% 1/2 W. Carbon T4 13 me IF Transformer 301-171-1
R68 3302 ± 10% 1/2W. Carbon T5 13 me IF Transformer 301-171-1
R69 1.2K ± 10% 1/2W. Carbon T6 455 kc IF Transformer 301-171-2
R70 152 ± 10% 1/2W. Carbon T7 455 kc IF Transformer 301-171-2
R71 2.22 ± 10% 1/2W. Carbon T8 455 kc IF Transformer 301-171-2
R72 2.22 ± 10% 1/2W. Carbon T9 Discriminator Transformer 301-172
R73 100K ± 10% 1/2W. Carbon
R74 33OS2 ± 10% 1/2W. Carbon (TM-02)
R75 2202 ± 10% 1/2W. Carbon
R76 IK ± 10% 1/2W. Carbon
R77 3.9M ± 10% 1/2W. Carbon
R78 10K ± 10% 1/2W. Carbon
R79 2202 ± 10% 1/2W. Carbon
R80 IK ± 10% 1/2 W. Carbon
R81 IK ± 10% 1/2W. Carbon
R82 10K ± 10% 1/2W. Carbon MISCELLANEOUS
R83 10K ± 10% 1/2W. Carbon
R84 IK ± 10% 1/2W. Carbon Ml Pilot Lamp 53
R85 2.2K ± 10% 1/2W. Carbon RY1 Resonant Reed Relay RD-5
R86 4702 ± 10% 1/2W. Carbon RY2 Relay 12V. KM-14D
R87 IK ± 10% 1/2W. Carbon Crystal ± .005% (Customer
R88 2.2K ± 10% 1/2W. Carbon to specify frequency) 101-835-3
R89 2.22 ± 10% 1/2 W. Carbon Y7 Crystal ± . 005% (Customer
R90 272 ± 10% 1/2 W. Carbon to specify frequency) 101-835-1
R91 to R100 NOT USED Y8 , Crystal ± . 002% (Customer
R101 IK ± 10% 1/2W. Carbon Y13t0 to specify frequency) 101-835-4
R102 1002 ± 10% 1/2W. Carbon Y14 Crystal ± . 002% (Customer
R103 500K Time Control - Mallory MTC-' to specify frequency) 101-835-2
R104 4.7K ± 10% 1/2W. Carbon Y15 Crystal 12.545 me ± .005% 101-834
R105 100K ± 10% 1/2W. Carbon JI Power Cord Assembly 101-913
R106 2.7K ± 10% 1/2W. Carbon J2 Antenna Jack 201-11-01-018
R107 IK ± 10% 1/2W. Carbon Antenna Plug 202-15-01-016
R108 1.8K ± 10% 1/2W. Carbon J3 Antenna Jack 201-11-01-018
R109 10K ± 10% 1/2W. Carbon J4 Remote Alarm Jack 2R2
R110 IK ± 10% 1/2W. Carbon Pl Power Plug 101-990
Rill IK ± 10% 1/2W. Carbon SP1 Speaker 301-102
R112 100K ± 10% 1/2W. Carbon cn t- Power Switch 101-734-4
R113 IM Time Control - Mallory MTC-4 cn N) Channel Selector Switch 301-169-2
R114 100K ± 10% 1/2W. Carbon cn W Channel Selector Switch 301-169-1
R115 IK ± 10% 1/2W. Carbon cn 4^ Tone Alarm Switch 301-186
R116 IK ± 10% 1/2W. Carbon Foot 100-435-1
R117 IK ± 10% 1/2W. Carbon Knob-Volume & Squelch 101-777-6
Knob-Channel & Alarm 101-777-7
Cabinet 600-163
Front Panel(single channel) 500-603
Front Panel(multi channel) 500-602
Back 301-161-1
Terminal Board-Speaker 300-079-7
Jewel-Pilot Lamp 150-001-2
Socket-Pilot Lamp 81L

18
