ITEM NO DESCRIPTION PART NO. ITEM NO DESCRIPTION PART NO.

COILS RESISTORS

LI (TM-L2) Ant. Coil Assy. 301-177-4 R1 2.5K Volume Control &
LI (TM-L1) Ant. Coil Assy. 301-177-8 On-Off Switch 101-734-4
L2 RF Output Coil Assembly 301-177-5 R2 25K Squelch Control 101-734-5
L3 1st L.O.Collector Coil Assy. 301-177-6 R3 4.7K ± 10% 1/2W. Carbon
L4 1st L.O.Emitter Coil Assy. 301-177-7 R4 10K ± 10% 1/2W. Carbon
L5 Antenna Coil 301-181-3 R5 IK ± 10% 1/2W. Carbon
L6 RF Output Coil 301-181-2 R6 4702 ± 10% 1/2W. Carbon
L7 1st L.O .Collector Coil Assy. 301-177-1 R7 10K ± 10% 1/2W. Carbon
L8 1st L.O. Emitter Coil Assy. 301-177-7 R8 10K ± 10% 1/2W. Carbon
L9 2nd L.O. Coil Assembly 301-177-3 R9 IK or 1.2 K ± 10% 1/2W. Carbon
Lil RF Filter Coil 300-097-1 R10 10K ± 10% 1/2W. Carbon
L12 RF Filter Coil 300-097-3 Rll IK ± 10 % 1/2W. Carbon
L13 RF Filter Coil 300-097-1 R12 4.7K ± 10% 1/2W. Carbon
R13 10K ± 10% 1/2W. Carbon
R14 10K ± 10% 1/2W. Carbon
R15 IK or 1.2K ± 10% 1/2W. Carbon
R16 1002 ± 10% 1/2W. Carbon
R17 22K ± 10% 1/2W. Carbon
R18 10K ± 10% 1/2W. Carbon
R19 IK ± 10% 1/2W. Carbon
R20 Not Used
R21 100Q ± 10% 1/2W. Carbon
TRANSISTORS R22 22K ± 10% 1/2W. Carbon
R23 10K ± 10% 1/2W. Carbon
Qi R . F. Amplifier S-1078 R24 NOT USED
Q2 Crystal Oscillator S-1078 R25 IK ± 10% 1/2W. Carbon
Q3 R. F. Amplifier S-1078 R26 100S2 + 10% 1/2W. Carbon
Q4 Crystal Oscillator S-1078 R27 27K ± 10% 1/2 W. Carbon
Q5 1st Mixer S-1078 R28 10K ± 10% 1/2W. Carbon
Q6 13 me IF Amplifier S-1078 R29 22K ± 10% 1/2W. Carbon
Q7 Crystal Oscillator(12.545mc) S-1079 R30 8.2K ± 10% 1/2W. Carbon
Q8 2nd Mixer S-1079 R31 IK + 10% 1/2W. Carbon
Q9 455 IF Amplifier S-1079 R32 IK ± 10% 1/2W. Carbon
Q10 455 IF Amplifier S-1079 R33 47fl + 10% 1/2W. Carbon
Qll 455 IF Amplifier S-1079 R34 100S2 ± 10% 1/2W. Carbon
Q12 Emitter Follower S-1080 R35 27K ± 10% 1/2W. Carbon
Q13 NOT USED S-1080 R36 10K + 10% 1/2W. Carbon
Q14 Squelch Control Amp. S-1080 R37 IK ± 10% 1/2W. Carbon
Q15 Squelch Control S-1080 R38 2.7K ± 10% 1/2W. Carbon
Q16 AF Driver S-1079 R39 100Q ± 10% 1/2W, Carbon
Q17 AF Output 2N2431MP R40 27K ± 10% 1/2W. Carbon
Q18 AF Output 2N2431MP R41 10K ± 10% 1/2W. Carbon
Q19 Power Regulator S-1081 R42 IK ± 10% 1/2W. Carbon
Q20 Tone Alarm Control S-1081 R43 2.7K ± 10% 1/2W. Carbon
Q21 Tone Switch Amp S-1079 R44 1000 ± 10% 1/2W. Carbon
Q22 Tone Switch S-1081 R45 22K ± 10% 1/2W. Carbon
Q23 Lamp Flasher 2N3638 R46 10K ± 10% 1/2W. Carbon
Q24 Lamp Flasher 2N3638 R47 IK ± 10% 1/2W. Carbon
Q25 to Q100 NOT USED R48 4.7K ± 10% 1/2W. Carbon
Q101 Tone Switch Amp S-1081 R49 82K ± 10% 1/2W. Carbon
Q102 Tone Switch Amp S-1080 R50 82K + 10% 1/2W. Carbon
Q103 Tone Switch Amp S-1080 R51 180K ± 10% 1/2W. Carbon
Q104 Tone Switch S-1080 R52 68K ± 10% 1/2W. Carbon
Q105 Flasher Lock On 2N3638 R53 4.7K + 10% 1/2W. Carbon
Q106 Timing Transistor S-1079 R54 NOT USED
Q107 Flasher Lock On 2N3638 R55 33K ± 10% 1/2W. Carbon
R56 22K ± 10% 1/2W. Carbon
R57 IK ± 10% 1/2W. Carbon
R58 4.7K ± 10% 1/2W. Carbon
R59 1.8K ± 10% 1/2 W. Carbon
R60 NOT USED
R61 NOT USED
R62 6.8K ± 10% 1/2W. Carbon
R63 12K ± 10% 1/2W. Carbon
17
