6
using lower power levels can also be uriven from standard alistic data with the models out of the wind tunnel wall
110 and 440 v systems in the facility, d-c motors can be boundary layer, a special ground board.is employed. This
powered from variable power supply equipment adjustable simulated ground plane shields all of the model supports
from 0-30 v. A full scale vehicle, for instance, could have which are level pads coincident with the ground plane. This
its fan driven and also its wheels rotated, if desired, with shielding prevents impingement of the mainstream on the
the available electrical power equipment. model supports, and thus eliminates large tare loads. To
SUPPORT EQUIPMENT - In addition to the normal sup reduce the boundary layer at the model to a minimum, there
port equipment used at the wind tunnel for testing aircraft is suction just aft of the ground plane lip so that only a small
models, there is also equipment designed to support testing boundary thickness exists at the model. A moving belt ground
of automobiles. Automotive support is permitted using ad plane is planned for this facility. When that capability ex
justable pads which can be varied in wheelbase from 75- ists, an automobile must be supported by a string attached
154 in., with a tread variation from 45-68 in. This full to a balance within the model. This type of support system
scale system can be installed in either of the two test sec will create an additional correction for base pressure effects.
tions. There is also a support system designed to a 3/8 scale ENVIRONMENTAL CONDITIONS - Environmental condi
of the above tread and wheelbase variations. tions existing in the test section would not affect hard sur
Full scale vehicles, assuming a frontal area of 25 sq ft, face models, but there may be some damage to modeling
can be tested very satisfactorily in the forward (large) test clay or soft models. The humidity is essentially that of the
section, but in the rear (smaller) section the data may be ambient air, and the temperatures range from below freez
questionable. In this case the blockage is about 6.5% of ing early on winter mornings to about 120 F maximum in
the test section area, and anything over 5% could create the summertime with tunnel shell cooling. This, however,
a deleterious pressure loss. Yaw runs to moderate angles is not unique in an aerodynamic low speed tunnel, where
could be conducted in the large section. design inputs do not include close control or environmental
For the purpose of obtaining interference effects, anothei conditions.
vehicle can be located near the test vehicle in any direc
CONCLUSION
tion with the reduced scale models and at any practical
displacement. Test data could be measured and recorded Since the wind tunnel is designed for aerodynamic testing
on the one vehicle attached to the balance. Full scale dual it has a good cross sectional velocity distribution with low
vehicle testing can be accomplished on in line close prox turbulence flow, and accurate steady state data can be ob
imity tests. This type of testing could help considerably tained. Because of the overall size and speed capability and
in understanding the interference phenomena of passing ve also because of the dual test sections, considerable data
hicles particularly between cars and trucks. can be obtained in the area of scaling effects. In this area,
All of the automotive support systems are attached to this facility can provide an opportunity not available to
the balance and are near the tunnel floor. To obtain re the automotive industry in any other wind tunnel.
