Attachment 3











                                TABLE II. MEASURED PLENUM CHAMBER PRESSURES                      *





                     Configuration* *            RPM = 3700      RPM = 4500      RPM = 5200      RPM = 6000
               Code         Description           Psi     ps2     Psi     Ps2     Psi     Ps2     Psi     Ps2

                1       BASE LINE                 .104    .104    .149    .157    .224   .224    .269    .269

                ID                                .134    .134    .179    .194    .224   .238    .299    .284


                IB                                .119    .119    .179    .179    .239    .224   .269    .284

                IB      plus nose extension       .119    .112    .172    .187    .232   .224    .269    .284
                        to simulate Dodge
                        Daytona

                2                                 .104    .090    .142    .112    .224   -.029   .269      0

                2       plus nose extension       .104    .134    .209    .090    .269   .209    .209   -.119
                        to simulate Dodge
                        Daytona



                * All pressures are gauge pressures in pounds per square inch.
              * * See Table I for configuration code definition.
